1/4" Micro Drill (Blue-Point®)

1/4" Micro Drill (Blue-Point®)

Specifications

Free Speed, RPM 1,800
Sound Pressure Level, dB(A) 96.4
Length, inches (mm) 7.2 (183)
Air Consumption, Free Speed, CFM (SCFM) [l/min] 1.9 (13.6) [53.8]
Recommended Air Pressure, PSIG (kPa) 90 (620)
Replacement Chuck only AT801MC-17
Air Inlet Thread Size, inches (NPT) 1/4 (18)
Chuck Cap., inches (mm) 1/4 (6)
Country of Origin JPN
Sound Level dB(A) Pressure 96.4
Rated Power, HP (kW) 0.25 (.19)
Vibration Level, m/s² <2.5
Spindle Thread, inches 3/8"-24 UNF
Recommended Hose Size, inches (mm) 3/8 (10) ID min.
Horsepower, HP 0.25
Weight, lb (kg) 1.5 (0.68)
Sound Level, dB(A) 96.4
Chuck Size, inches (mm) 1/4 (6)
Air Consumption, Average, CFM (SCFM) [l/min] 1.9 (13.6) [53.8]
Chuck Key AT801MC-18

MPN: AT801MCA
